Single push-button CTAA-01/04 single button, without LED, without Rocker, without Frame for 55mm Systems
This product is no longer in stock
Push-button Unit universal 55x55mm, without LED
• When pressed, the push-button unit transmits a signal to the actuators of the convenient
electrical installation system. No distinction is required between a dimmer switch or
change-over switch, intermediate switch or blinds switch, etc. The device is powered by a
coin cell (CR2450N). Therefore it can be conveniently attached (screw-mounted or glued)
wherever needed. Thanks to the flat design NO installation box or branch-off box is
required. The push-button is compatible with several 55x55 mm wall switches.
Frames and rockers are available in white, cream, anthracite and black.
• Battery included.
|Power supply||3V via CR2450N battery|
|Number of rockers depending on type|
|Type of transmission||Bi-directional, via coded telegrams|
|Indoor range||Typically 30 - 50m, 2 walls + 1 ceiling (depending on wall thickness, material, used rocker and frame !!)|
|Service life of the battery||Approx. 10 years (= battery life)|
according to application, battery manufacturer,
time of actuation: typically
120.000 switching operations at room temperature
40.000 blind operations at room temperature
24.000 dimming cycles at 5 seconds dimming time
and room temperature
|Degree of protection||IP20|
|Degree of soiling||2|
|Operating temperature||+5 to +45°C|
|Storage/transportation temp.||-25 to +70°C|
|Colour of the push-button base||similar to RAL7035|
|Colour of the the mounting plate||similar to RAL7035|
|Size of push-button base HxWxD||55 x 55 x12.2mm|
|Size of the mounting plate HxWxD||70 x 70 x 10mm|
|Approval||Printed onto the device|
