CAAE-01/01 Analogue 0-10VDC

This device can receive wireless signals and adjust an output setting accordingly, a simple example is reading from a temperature sensor which this unit then adjusts the heating/ventilation in a room accordingly.

The analogue actuator receives wireless signals, switches a relay and provides an output voltage of 0-10VDC for terminals such as mixers, heating, ventilation, dimmers etc. The device is mains supplied and can be incorporated into installation boxes, intermediate ceilings or directly into the devices to be controlled.

Control is from a standard wireless analogue unit via the xComfort wireless mesh network.

• Power supply 230VAC, 50Hz
• All connections Single-wired 1.5mm² connections
• Load 230VAC, 50Hz, 8A resistive load The device switches L via LA Internal protection through thermal protection
• Pre-protection Power circuit breaker 16A, charateristic C
• Control output 0-10VDC, max. 20mA internal electronic overload protection
• Frequency 868,300 MHz
• Type of transmission Bi-directional, via coded telegrams
• Indoor range Typically 30 - 50m, 2 walls + 1 ceiling (depending on wall thickness and material !!)
• Degree of protection IP20
• Degree of soiling 2
• Operating temperature -5 to +45°C
• Storage /transportation temp. -25 to +70°C
• Colour of the frame Grey, RAL7035
• Size of the frame HxWxD - 150 x 34 x 28mm
• Approval Printed onto the device
