CAAE-01/02 Analogue 1-10VDC

This device will receive signals wirelessly and directly control the levels of electronic fluorescent lamps, although other devices can also be controlled.

The analogue actuator receives wireless signals, switches a relay and actuates a control voltage of 1-10VDC for dimmers and electronic ballasts of fluorescent lamps also known as DSI controlled. It is mains supplied and can be incorporated into an installation box, an intermediate ceiling or directly into fluorescent lamps.

Control is from a standard wireless analogue unit via the X-Comfort wireless mesh network.

8A/230VAC, 20mA/1-10VDC

CAAE-01/02

• Power supply 230VAC, 50Hz
• All connections Single-wired 1.5mm² connections
• Load 230VAC, 50Hz, 8A resistive load The device switches L via LA Internal protection through thermal protection
• Pre-protection Power circuit breaker 16A, charateristic C
• Control output 1-10VDC, max. 20mA internal electronic overload protection
• Frequency 868,300 MHz
• Type of transmission Bi-directional, via coded telegrams
• Indoor range Typically 30 - 50m, 2 walls + 1 ceiling (depending on wall thickness and material !!)
• Degree of protection IP20
• Degree of soiling 2
• Operating temperature -5 to +45°C
• Storage /transportation temp. -25 to +70°C
• Colour of the frame Grey, RAL7035
• Size of the frame HxWxD - 150 x 34 x 28mm
• Approval Printed onto the device
